Core Working Principle
The machine utilizes centrifugal disc finishing technology. Workpieces and abrasive media are placed in a stationary process drum, while a rotating disc at the bottom generates high-speed centrifugal force, creating an intense toroidal flow.
Processing Efficiency: Generates finishing forces 10–20 times greater than conventional vibratory systems, dramatically reducing cycle times.
Toroidal Movement: Creates a spiral motion that prevents workpieces from sticking together, ensuring uniform and precise material removal.
Wet & Dry Dual-Mode System
Wet Processing Mode
Ideal for deburring, edge radiusing, grinding, and mirror polishing. Chemical compounds enhance lubricity and cutting performance of the abrasive media. Equipped with automatic recirculation water system and compound dosing system for stable, consistent results.
Dry Processing Mode
Designed for polishing tarnished or worn jewelry, rust removal, and surface restoration. Uses pre-impregnated walnut shell granules with polishing paste as the abrasive media. Features an integrated heat dissipation system that cools the media during processing, preventing thermal damage to workpieces.
Key Features
Versatile Dual-Mode Operation
Supports both wet and dry processing with quick changeover between modes. Multi-bowl configurations (1–4 bowls) allow simultaneous operation of different processes (e.g., wet + dry), significantly boosting productivity.
Intelligent Control
Equipped with touchscreen PLC control system, capable of storing 99 to 5,000 programmable recipes covering speed, time, compound ratios, and all critical parameters.
Robust & Durable Construction
Process drums feature hot-molded PU (polyurethane) lining with wear resistance 8 times higher than steel, protecting workpieces from damage. Gap systems utilize high-wear materials including ceramic, tungsten alloy, and manganese steel for extended service life.
