H-Speed Curve Polishing Machine

Product Introduction:

The H-Speed Curve Polishing Machine is a high-speed precision polishing system specifically designed for 2.5D and 3D curved workpieces. Featuring a synergistic structure of high-speed rotating polishing heads and multi-station workpiece plates, the machine combines rotary and planetary motion to achieve efficient sweep polishing of curved surfaces on non-metallic hard-brittle materials (glass, ceramics, sapphire) as well as metallic materials (aluminum alloy, stainless steel).
This model is widely used in the curved surface polishing of consumer electronics components including mobile phone cover glass, tablet touchscreens, and optical lenses.

Send Inquiry

Description

Technical Parameters

Core Working Principle

The machine operates on a combined rotary-planetary motion principle. Workpieces are vacuum-secured onto workpiece plates, which rotate on their own axis while revolving around the central axis. The upper polishing heads rotate independently (up to 700rpm) and apply uniform pressure across the curved surfaces of workpieces, achieving complete, no-blind-spot sweep polishing.

Independent polishing head lifting devices allow automatic height adjustment for different curvature profiles, ensuring stable and controllable polishing pressure.

Key Features

High-Speed & High-Efficiency Polishing

The polishing heads feature high-speed rotation up to 700rpm. Combined with multi-stage sweep polishing processes, this significantly improves processing efficiency and reduces cycle time per workpiece.

No-Blind-Spot Sweep Polishing

The combined planetary motion (revolution + rotation), paired with cylinder and servo automatic compensation, ensures full coverage of every curved surface and edge-achieving uninterrupted, no-blind-spot uniform polishing.

Precision Pressure Control

Equipped with a pressure balance system (PLC + proportional valve + pressure sensor), the machine monitors and stabilizes polishing pressure in real time, ensuring consistent finishing quality across batches and improving yield rates.

Vacuum Adsorption & Automatic Drainage

A vacuum adsorption system with digital vacuum gauge monitors negative pressure in real time, ensuring workpieces remain securely fixed even at high speeds. The machine also features a vacuum gas-liquid separation device for automatic drainage.

Corrosion-Resistant Construction

All liquid tanks, cabinet panels, and liquid basins exposed to polishing fluid are made of corrosion-resistant materials such as stainless steel or aluminum alloy, ensuring stable and efficient long-term performance.

Intelligent Control

The human-machine interface touchscreen combined with PLC programmable controller delivers intuitive operation and supports presetting and storage of multi-stage process parameters.
